Envelope and T.A.P. density of shaped pieces and compacted powders – without the use of hazardous materials (DryFlo medium)



  • Measures envelope volume/density and, optionally, T.A.P. density (ASTM D8097)
  • DryFlo medium – dry solid beads, free of hazardous substances, non-destructive to the sample
  • Results in as little as ~15 minutes, high repeatability (typically ± 1.1%)
  • Combined with skeletal density (AccuPyc), gives pore volume and porosity of shaped pieces
GeoPyc

Details

  • Model: GeoPyc 1365
  • 5 sample chamber sizes (12.7-50.8 mm ID), for sample volumes from 0.3 to 25 cm³
  • Intelligent touch screen, fully automated data collection and reporting (CSV export, email/web viewing)
  • User-replaceable plunger tip, easy cleaning – low maintenance cost
  • Application: formed/shaped pieces (tablets, granules, pellets, roller-compactor ribbons, sintered parts)



Repeatability When sample volume is at least 25% of chamber volume: typically ± 1.1%
Sample chambers 12.7 mm ID: 0.3-0.8 cm³ · 19.1 mm ID: 0.8-2.4 cm³ · 25.4 mm ID: 2.4-5.3 cm³ · 38.1 mm ID: 5.3-13 cm³ · 50.8 mm ID: 13-25 cm³
Physical dimensions 28 × 56 × 38 cm / H×W×D (originally 11 × 22 × 15 in); weight 19 kg (42 lbs)
Power 85-265 VAC, 47-63 Hz, 95 VA
Operating environment 15°C to 35°C; humidity 20-80% (non-condensing)

Source: micromeritics.com/products/geopyc (technology, software, features and capabilities) and the GeoPyc 1365 brochure (Micromeritics, internal archive).
